InterSigma ZPG 5 Gearpump Agent
InterSigma ZPG 5 Gearpump
Gearpump InterSigma Low Pressure Pump Type ZPG
The InterSigma ZPG Gearpump pump comes from the Czech Republic at Továrnà 605, 753 01 Hranice with the company SIGMA PUMPY HRANICE, s.r.o.
InterSigma ZPG 5 Gearpump Specifications
The InterSigma ZPG 6 gearpump has a pipe diameter of 1.5 icnh (DN 40), pressure of 2 to 6 bar, capacity of 0,750 l/s to 2,383 l/s with electrical power from 0.5 kW to 3.1 kW.
InterSigma ZPG 5 Gearpump App
In general, ZPG low pressure − pressure pumps are intended for the delivery of fluids with lubricating capacity without the content of mechanical abrasive solids.
Max. pumped liquid temperature: 80°C
Max. pump delivery pressure: 6 bar
InterSigma gearpumps are provided to pump all types of oils, petroleum, thinners, emulsions, foams, molasses, tars, lyes, varnishes, soluble glass, etc.
InterSigma gearpumps are also applicable to lubrication and cooling systems
various machines and aquipments, for − hyd− low pressure
raulic drives, etc.
InterSigma ZPG 5 Gearpump Rotation
Standard operation of the pump is clockwise, viewed from the drive side.
In special applications pumps can be provided as counter-clockwise, but with the reverse direction of the fluid being delivered.
InterSigma ZPG 5 Gearpump Material
The specified InterSigma ZPG 5 Gearpump material consists of the main parts of the following materials:
pump casing, shield/cover, stuffing box housing are from gray cast iron; gears and shafts are from carbon steel; Bearing bushes are of carbon steel with bronze coating.
We are the InterSigma ZPG 5 Gearpump Agent in Jakarta with stock available.
Intersigma Gearpump ZPG 5
